인화점시험기 (Flash Point Meter) RT-01
페이지 정보
본문
인화점시험기 (Flash Point Meter) RT-01
| 제조사 | Erdco |
|---|---|
| 원산지 | USA |
| 브랜드 | Erdco |
| 모델 | RT-01 |
| 판매가격 | 견적문의 |
| 다운로드 |
제품상세
가연성 성분을 함유한 액체의 인화점을 측정하는 실험기기
화씨 및 섭씨온도를 선택적으로 LCD 화면에 표시
[Model detail]
| Model | RT-01 |
| Performance | |
| Repeatability | 0.5°C - 70°C 2.0°C - 150°C |
| Reproducibility | 2.0°C - 70°C 7.5°C - 150°C |
| Test Time | 1min below 100°C 2min above 100°C |
| Characteristics | |
| Cup Type | RT-01 Closed RT-02 Open |
| Cup Material | Aluminum (Stainless steel optional) |
| Dimensions | 381㎜ × 86㎜ ×162㎜ (W × L × H) |
| Display | LCD digital and NIST traceable mercury-in- glass thermometer |
| Net Weight | 10 lbs (4.6 kg) |
| Power Requirements | 230v, 50/60 Hz |
| Sample Size | 2 ml below 100°C 4 ml above 100°C |
| Temperature Range | -30°C ~ 300°C |
| In Accordance with | |
| ASTM D 3278 | Flash point of liquids by small scale closed cup apparatus |
| ASTM D 3828 | Flash point by small scale closed tester |
| ASTM D 4206 | Sustained burning of liquid mixtures using the small scale Open-cup apparatus |
| BS 3900 Part A11 | Small scale test for combustibility |
| BS 3900 Part A13 | Rapid test for flash point - Danger Classification |
| BS 3900 Part A14 | Rapid tsets for flash point - Paints and Varnishes |
| CPSC CFR 16-1500.43a | Federal hazardous substances act regulations |
| DOT CFR 49-173.115 | Flammable, Combustible, and Pyrophoric liquids, definitions |
| IATA Resolution 618 Attachment A | Section 3.3.4 ajnd 3.3.5 |
| IP 303 | Flash point by closed rapid tester |
| ISO 3679 | Paints, Varnishes, Petroleum and Flash point - Rapid Equilibrium Method |
| ISO 3680 | Paints, Varnishes, Petroleum and Related Products - Flash/No Flash Test - Rapid Equilibrium Method |
| OSHA 29CFR 1910-106 | Program Diective 100 |
| OSHA 29CFR 1910-1200 | Hazard Communication |
